Outside Antenna Installation Running Antenna Cable Connect Coax Cables to Drive 4G-S
Connect Power Supply to Drive 4G-S Connect to Power Supply Mount Dash Bracket (optional).
Select a location on top of the vehicle to mount the Mini-Mag
Mount Antenna that is:
Run the Outside Antenna cable into the car. The cable is strong
enough that it may be shut in most vehicle doors without damaging
the cable. For a cleaner look, carefully pull down the door seal, run
the cable under the seal, and push the seal back into place. This
method reduces wear on the cable as the door opens and closes.
Connect the cable from the Mini-Mag Mount Antenna to the
connector on the bottom of the Drive 4G-S.
Plug the power adapter into vehicle’s 12V DC power supply. If your
Drive 4G-S is working correctly, the light will be green.
NOTE: If lights are not green on your weBoost booster, please refer
to the full install guide online or contact customer support at
1-866-294-1660 or email at support@weboost.com.
1 2 3
4 5 6
DC Power Adapter
Vehicle’s Power Supply
Dash Mount Bracket
Drive 4G-S
n
Near the center of the vehicle’s
roof.
n
At least 12 inches from any
other antennas.
n
Free of obstructions.
n
At least 6 inches from any
windows (including sunroofs).
Connect the power cable to the connector on the bottom of the
Drive 4G-S.Slide cell phone into cradle (may have to adjust arms in
different slots to t your cell phone).
Mini-Mag Mount Antenna
Clean the area where the bracket is to be mounted with the alcohol
wipe included. Allow the area to dry. Peel the backing to expose
the adhesive and press the bracket onto the desired location on
the dashboard. Attach the Drive 4G-S by aligning the rectangular
hole on the back with the tab on Mounting Bracket pushing
downward.
Drive 4G-S
