PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE 4G-X FLEET
______
(STEP 1 cont.)
Position threads of the cable mount above vehicle surface.
Apply included silicone grease to the o-ring on the collar
then screw the collar to the base mount. Ensure the mount is
centered in the hole and tighten with wrench.
Before attaching the antenna, clean the area around the
mount. Apply a thin layer of silicone grease to the threads,
only, of the NMO mount and to the o-ring on the antenna.
DO NOT apply to the antenna pin contact surface. Screw the
antenna onto the NMO mount and hand tighten into place.
Ensure the antenna is screwed all the way in and make sure
the casket is touching the vehicle surface.
apply silicone
grease
hand tighten
screw on
NMO Antenna
screw collar
to base mount
