5
(STEP 2 cont.)
3-Way Antenna
Mount with hardware
Side Exit
Adapter
Spring
Mast Extension
If installing with the Spring, disassemble
the 3-Way Mount and use disc washer
and nut (provided) to mount the Outside
Antenna with Spring as shown.
add Thread
Locker
add Thread
Locker
Remove nut &
shakeproof washer
Remove bolt, lock
washer & plastic
washer
Mount disc washer with lip
in the DOWN position
Fasten nut with lip in
the UP position
