Signal Booster Specifications
Signal 3G™
Model Number 460009
Connectors SMA-Female
Antenna Impedance 50 Ohms
Frequency 824-894 MHz & 1850-1995 MHz
Passband Gain (nominal)
800 MHz
13.4
1900 MHz
12.3
20 dB Bandwidth (MHz)
800 MHz 1900 MHz
Typical
Maximum
41.7
43.3
84.1
88.9
Power output for single cell phone (dBm)
800 MHz 1900 MHz
Uplink
Downlink
23.8
-6.05
22.3
-6.3
Power output for multiple received channels
(Uplink) dBm
No. Tones
800 MHz 1900 MHz
2 24.1 23.2
3 20.5 19.6
4 18.0 17.1
5 16.1 15.2
6 14.5 13.6
Power output for multiple received channels
(Downlink) dBm
No. Tones
800 MHz 1900 MHz
2 -3.2 -4.7
3 -6.7 -8.2
4 -9.2 -10.7
5 -11.1 -12.7
6 -12.7 -14.2
Noise Figure (typical downlink/uplink) 4 dB (nominal)
Isolation > 60 dB
Power Requirements 5V DC, 1A
The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating
would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This power
reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device.
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory
reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order to increase coverage of
authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal is detected. If a detected signal is
too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster will automatically turn the power off on that band. For a
detected oscillation the Signal Booster will automatically resume normal operation after a minimum of 1 minute. After 5 (five) such automatic restarts,
any problematic bands are permanently shut off until the Signal Booster has been manually restarted by momentarily removing power from the Signal
Booster. Noise power, gain, and linearity are maintained by the Signal Booster’s microprocessor.
