B600 Service Manual
1. Standart equipment
Cleaner with oating cover and 40 m oating cable
Filter system
Trolley with safety transformer
2.TechnicalspecicationsB600
Manufactured in accordance with 89/392/EEC and EN60-335-1 plus EN60-204 for remaining parts.
2.1 The cleaning unit
Dimension, L*W*H (mm) 860x600x300 mm
Weight in air approx. 50 kg
Weight in the water approx. 7 kg
Suction width 600 mm
Maximum suction capacity 1000 l/mn
Maximum depth of operation 7m
Speed 0,2 and 0,4 m/s with 50Hz
Maximum water temperature 40 º C
Pump motor 42 VAC, 3 phases 50/60 Hz
Power rating 2,3 kW
Drive motor 42 VAC, 3 phases 50/60 hZ
Power rating 0,15/0,25 kW
Maximun noise level 70 dB
Sealing classication IP 68
2.2 The trolley and the safety transformer
Dimension, L*W*H (mm) 1200x600x980 mm
Safety transformer 3 kVA
Primary voltage 208/400/230 V, 380/400/415 V
Maximun secondary voltage 50 V (free runing)
Sealing classication IP45
Overcurrent relay 12/5,7/5,5 A
