WEG MPW18 - Page 16

C-14
Low Voltage Industrial Controls
1-800-ASK4WEG | www.weg.net/us
Data is subject to change without notice.
MPW18 & MPW40
Models
Setting
overload
release
(A)
220-230 V ac 380-415 V ac 440 V ac 460-500 V ac 630-690 V ac
Icu Ics Icu Ics Icu Ics Icu Ics Icu Ics
kA kA kA kA kA kA kA kA kA kA
MPW12...18
0.10...0.16 100 100 100 100 100 100 100 100 10 10
0.16...0.25 100 100 100 100 100 100 100 100 10 10
0.25...0.4 100 100 100 100 100 100 100 100 10 10
0.4...0.63 100 100 100 100 100 100 100 100 10 10
0.63...1 100 100 100 100 100 100 100 100 10 10
1...1.6 100 100 100 100 100 100 100 100 10 10
1.6...2.5 100 100 100 100 100 100 100 100 8 8
2.5...4 100 100 100 100 100 100 100 100 8 8
4...6.3 100 100 100 100 100 100 100 100 8 8
6.3...10 100 100 50
10 50 10 10 10 5 5
10...16 100 100 10 10 10 10 10 8 4 3
12...18 100 100 10 10 10 10 10 8 4 3
MPW40
0.10...0.16 100 100 100 100 100 100 100 100 100 100
0.16...0.25 100 100 100 100 100 100 100 100 100 100
0.25...0.4 100 100 100 100 100 100 100 100 100 100
0.4...0.63 100 100 100 100 100 100 100 100 100 100
0.63...1 100 100 100 100 100 100 100 100 100 100
1...1.6 100 100 100 100 100 100 100 100 100 100
1.6...2.5 100 100 100 100 100 100 100 100 8 8
2.5...4 100 100 100 100 100 100 100 100 8 8
4...6.3 100 100 100 100 100 100 100 100 8 8
6.3...10 100 100 100 100
50 25 42 21 8 8
10...16 100 100 50 25 50 15 10 8 5 5
16...20 100 100 50 25 50 15 10 8 5 5
20...25 100 100 50 25 50 15 10 8 5 5
25...32 100 100 50 25 25 15 10 8 5 5
32...40 100 100 30 15 20 10 10 5 5 2
Model
Setting
overload
release
(A)
380-415 V ac 440 V ac 460-500 V ac 630-690 V ac
Icu Ics Icu Ics Icu Ics Icu Ics
kA kA kA kA kA kA kA kA
MPW40 +CLT32 MPW40
0.10...0.16
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
0.16...0.25
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
0.25...0.4
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
0.4...0.63
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
0.63...1
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
1...1.6
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
1.6...2.5
♦ ♦ ♦ ♦ ♦ ♦
50 50
2.5...4
♦ ♦ ♦ ♦ ♦ ♦
50 50
4...6.3
♦ ♦ ♦ ♦ ♦ ♦
50 50
6.3...10
♦ ♦
100 100 100 100 50 50
10...16 100 100 100 100 100 100 50 50
16...20 100 100 100 100 100 100 50
50
20...25 100 100 100 100 100 100 10 10
25...32 100 100 100 100 100 100 10 10
MPW Manual Motor Protectors - Rated Short-Circuit
Breaking Capacity (IEC 60947-2)
MPW Manual Motor Protectors + CL
T32 Current Limiter
Rated Short-Circuit Breaking Capacity (IEC 60947-2)
MPW40+CLT32 MPW40
