Front Auxiliary Contact Block - ACBF
Left Side Auxiliary Contact Block - ACBS
For use with
Auxiliary contacts
Catalog # List Price
NO NC
MPW18
MPW40
1)
1 1 ACBS-11-B
$22.002 - ACBS-20-B
- 2 ACBS-02-B
For use with
Illustrative picture
Auxiliary contacts
Catalog # List Price
NO NC
MPW18
MPW40 1 1 ACBF-11-B $20.00
Trip Signalling Block - TSB
2)
Undervoltage Release - URMP
1)
For use with Description Catalog # List Price
MPW18
MPW40
- Equipped with 2 auxiliary contacts (1NO + 1NC) for overload trip signalling and 2 other
auxiliary contacts (1NO + 1NC) for short-circuit trip signaling;
- To reset the circuit breaker after a short-circuit, the flag must be manually reset after the
cause of the failure has been solved;
- Lateral auxiliary contacts can be assembled together with the trip signalling block;
- Left side assembly only.
TSB-22-B $38.00
For use with Description Voltage and frequency
2)
Catalog # List Price
MPW12/18
MPW40
- Operating voltage:
>0.85...1.1 x Ue
- Non operating voltage:
<0.35...0.7 x Ue
- Right side assembly
220 V 50/60 Hz URMP D23-B
$56.00
24 V 50/60 Hz URMP D02-B
110 V 50 Hz / 120 V 60 Hz URMP V18-B
180 V 50 Hz / 208 V 60 Hz URMP V23-B
208 V 50 Hz / 240 V 60 Hz URMP V30-B
400-415 V 50 Hz / 480 V 60 Hz URMP V47-B
Shunt Release - SRMP
1)
Notes: 1) TSB, URMP, AND SRMP are only available with screw terminals.
The following accessories can be assembled at the same time: ACBF + URMP/SRMP + TSB or ACBS + URMP/SRMP + TSB.
For use with Description Voltage and frequency
2)
Catalog # List Price
MPW12/18
MPW40
1)
- Operating voltage:
0.7...1.1 x Ue
- Right side assembly
20-24 V 50/60 Hz SRMP D51-B
$56.00
100-127 V 50/60 Hz SRMP D59-B
200-240 V 50/60 Hz SRMP D65-B
