1 - MPW40 motor protective circuit breaker (screw terminal)
2 - Feeder terminal FTBBS
3 - Three-phase busbars BBS
4 - Push-in-lugs PLMP
5 - Side mounted auxiliary contact block ACBS (screw terminal)
6
- Undervoltage release URMP or shunt release SRMP
(screw terminal)
7 - Front mounted auxiliary contact block ACBF (screw terminal)
8 - Door coupling rotary handle RMMP
9 - Door coupling rotary handle MRX
1
0 - Front plate FME55
11 - Standard insulated enclosure PE55GN-E
12 - Large insulated enclosure LPE55GN-3
13 - Trip signaling block TSB
14 - LST25 - Feeder terminal for “Type E” motor starter
according to UL
15 - Current limiter CLT32 MPW40
16 - Scale cover SCMP
17 - Link module ECCMP-40B38 (MPW40+CWB9...38)
18 - CWB9...38 contactors
5
3
2
4
14
1
17
18
13
1
7
9
8
10
6
1
11
12
15
16
MPW40 Manual Motor Protector - Overview
