iPump Quick Start Guide 7
800009-02 Rev.B
Table 1 (continued). LED Indicator Descriptions
Indicator
Label
Color and
State
Meaning
COMPEL
Off COMPEL is not required and not
received within the last two
minutes; or, iPump is not in
tracking mode.
GREEN
constant
Current transport stream is
protected by conditional access
(CA) and iPump is authorized and
descrambling.
GREEN
slow blink
Current transport stream is
protected by conditional access
(CA) but iPump is unauthorized.
AUTH
Off Tracked channel is not scrambled
("in the clear").
AMBER
constant
One or more warning conditions
exist. Read warning information
from front-panel LCD.
WARNING*
Off No warning conditions exist.
RED
constant
One or more alarm conditions
exist. Read alarm message from
LCD.
ALARM*
Off No alarm condition exists
∗
∗∗
∗
Only one alarm or warning condition is displayed at a time
on the LCD. When multiple alarm or warning conditions
exist, those conditions are displayed in the order of
importance. The most critical condition is displayed first and
others may be viewed by pressing the right arrow button( ).
