Weider WEBE0635.1 - Page 8

8
10. Insert a Pad Tube (9) into the Leg Lever (7). Slide
two Foam Pads (10) onto the Pad Tube.
Repeat this step with the other Pad Tube (9).
11. Attach the Inner Bar (18) to the Outer Bar (19)
with the two Roll Pins (28).
12. Make sure that all parts have been properly tight-
ened. The use of the remaining parts will be
explained in ADJUSTMENTS, beginning on the
next page.
7
10
11
10
10
9
9
18
19
28
28
