12
18. Attach the Curl Pad (44) to the Curl Post (42) with
two M6 x 16mm Screws (3).
18
42
3
44
19. Press a 1Ó Round Inner Cap (32) into the end of each
Weight Rest (21).
Insert the Weight Rests (21) into one set of holes in
the Uprights (1). Turn each Weight Rest until the lock-
ing clip snaps into place around the Upright. Make
sure both Weight Rests are set at the same
height.
19
32
21
32
21
1
1
20. Make sure all parts are properly tightened before you use the weight bench. The use of all remaining
parts will be explained in ADJUSTING THE WEIGHT BENCH starting on the next page.
