PART IDENTIFICATION CHART
M10 Washer (29)
M6 Washer (31)
M8 Nylon Locknut (43)
M10 Spacer (42)
M8 x 35mm Carriage Bolt (36) M8 x 68mm Bolt (28)
M8 x 55mm Bolt (22)
M10 x 168mm Bolt (40)
M10 x 67mm Bolt (46)
M8 Washer (41)
M10 Nylon Locknut (45)
M8 x 16mm Bolt (44)
M6 x 50mm Screw (38)
M6 x 16mm Screw (10)
M6 x 38mm Screw (14)
M10 x 55mm Bolt (49)
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
