19
42. Attach the Curl Pad (9) to the Curl Post (8) with
two M6 x 16mm Screws (29).
Press two Adapter Bushings (15) into the Weight
Adapter (18).
42
9
8
18
15
29
15
43. Make sure that all parts are properly tightened
before the weight bench is used. The use of all
remaining parts will be explained in ADJUST-
MENTS, beginning on the following page.
