REMOVE THIS PART LIST/EXPLODED DRAWING
FROM THE MANUAL
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
1 1 Left Seat Bracket
2 1 Leg Lever Lock
3 1 Leg Lever
4
1 Front Leg
5 1 Bench Frame
6 1 Left Base
7 1 Right Base
8 1 Left Upright
9 1 Right Upright
10 1 Curl Post
11 2 Weight Rest
12 1 Adjustment Tube
13 1 Left Backrest Tube
14 1 Right Backrest Tube
15 1 M10 x 65mm Bolt
16 1 Long Pad Tube
17 2 Short Pad Tube
18 6 Foam Pad
19 1 Right Seat Bracket
20 2 Plastic Spacer
21 4 M8 Washer
22 1 Seat
23 1 Backrest
24 1 Curl Pad
25 2 M10 Adjustment Knob
26 1 M8 Adjustment Knob
27 3 45mm Square Inner Cap
28 2 Upright Stabiliser
29 2 2” Square Inner Cap
30
2 1” Round Inner Cap
31 6 3/4” Round Inner Cap
32 2 1” Square Inner Cap
33 2 1 1/2” Square Inner Cap
34 2 1 1/4” Square Inner Cap
35 4 10mm Plastic Bushing
36 4 M6 Washer
37 2 M10 Washer
38 1 M8 x 60mm Bolt
39 3 M8 x 16mm Bolt
40 9 M8 Nylon Locknut
41 1 M10 x 73mm Bolt
42 4 M8 x 67mm Bolt
43 1 M10 x 175mm Bolt
44 4 M6 x 40mm Bolt
45 6 M6 x 16mm Bolt
46 2 Outer Upright Bushing
47 2 M8 x 55mm Carriage Bolt
48 2 M8 x 62mm Bolt
49 3 M10 Nylon Locknut
50 1 1 3/4” Slotted Square Inner Cap
# 1 User’s Manual
# 1 Exercise Guide
Key No.
Qty. Description Key No. Qty. Description
SAVE THIS PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE
Part List—Model No. WEEVBE33110
R0404A
