WEEVSY62000 R0301A
Note: Assembly is divided into four stages: 1) frame assembly, 2) arm assembly, 3) cable and pulley
assembly, and 4) seat and backrest assembly. The hardware for each stage is packaged separately.
WAIT UNTIL YOU BEGIN EACH ASSEMBLY STAGE TO OPEN THE PARTS BAG LABELLED FOR THAT
ASSEMBLY STAGE.
This chart is provided to help you identify the small parts used in assembly. Important: Some parts may have
been pre-assembled for shipping purposes. If you cannot find a part in the parts bags, check to see if it
has been pre-assembled. The number in parenthesis below each part refers to the key number of the part. The
second number refers to the quantity needed for assembly.
REMOVE THIS PART IDENTIFICATION
CHART FROM THE MANUAL
