31
9427370000_00/06.2019
DC Volts
R
ange
660mV
6.6V
66V
660V
1000V
Resolution
0.1mV
1mV
10mV
100mV
1V
Accuracy
± (0.5% rdg + 2d)
± (0.5% rdg + 2d)
± (0.5% rdg + 2d)
± (0.5% rdg + 2d)
± (0.5% rdg + 2d)
Input Impedance
>100MΩ
10MΩ
9.1MΩ
9.1MΩ
9.1M
Ω
Overload protection: 1000V DC or 750V AC rms
AC Vo
lts (True RMS)
Range
660mV
6.6V
66V
660V
750V
Resolution
0.1mV
1mV
10mV
100mV
1V
Accuracy (50~500Hz)
± (1.5% rdg + 8d) 50~100Hz
± (1.5% rdg + 8d) 50~500Hz
± (1.5% rdg + 8d) 50~500Hz
± (1.5% rdg + 8d) 50~500Hz
± (1.5% rdg + 8d) 50~500Hz
Input Impedance
> 100MΩ
10MΩ
9.
1MΩ
9.1MΩ
9.1MΩ
Cr
est Factor: ≤ 3
Peak Hold: ±(3.0% rdg + 200 dgts) on 66V to 750V ranges
AC coupled true rms specified from 5% to 100% of range
FREQUENCY Ranges: 50Hz ~ 1kHz.
Accuracy:
± (0.1% rdg + 5 dgts)
Minimum Input voltage Range: >500dgts.
The readings of frequency measurements will show on the sub-
display.
Overload protection: 1000V DC or 750V AC rms
