%Duty Cycle
Range
5% to 95%
Resolution
0.1%
Pulse Width
>10
μ
s
Acc
uracy ( 5V logic)
±(2.0% rdg+10d)
Frequen
cy range: 5% to 95% ( 40Hz to 20kHz )
The readings of % DUTY CYCLE measurements will show on the sub-
display.
Overload protection: 600V DC or AC rms
Frequency
Range
66Hz
660Hz
6.6kHz
66kHz
660kHz
1MHz
Resolution
0.01
Hz
0.1Hz
1Hz
10Hz
100Hz
1kHz
Accuracy
±(0.1% rdg
+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
Trigge
r Level
>3.5V
>3.5V
>3.5V
>3.5V
>3.5V
>3.5V
Minimum Inp
ut Range: > 10Hz
Minimum pluse width: > 1μs
Duty cycle limits: > 30% and < 70%
Overload protection: 600VDC or AC rms
