Installation and operating instruction
Room device WEM-RG1
5 Operation
83310002 1/2017-11 La
11-20
5.2 Display
1 Active mode (e.g. manual operation)
2 Summer setting activated (no heating operation)
3 Setback activated (reduced temperature level)
4 Normal operation activated (normal temperature level)
5 Comfort mode activated (increased temperature level)
6 Fault
(1
7 Current room temperature (standard display); parameters and values
8 Setting mode activated
9 Service note
(2
Faults
(1
If there is a fault in the system, a warning symbol appears in the display.
If an interlocking fault occurs, the warning symbol flashes, the system goes to lock-
out.
Notify Weishaupt Customer Service or your heating contractor.
Service note
(2
If the service interval of the condensing boiler has been exceeded, an spanner
wrench appears in the display.
Notify Weishaupt Customer Service or your heating contractor.
