Installation and operating instruction
Room device WEM-RG1
4 Installation
83310002 1/2017-11 La
8-20
4 Installation
DANGER
Risk of electric shock
Working on the device when voltage is applied can lead to electric shock.
Isolate the device from the power supply prior to starting any work.
Safeguard against accidental restart.
The electrical connection must only be carried out by qualified electricians. Ob-
serve local regulations.
If only 2 wires are available on site, the connection can be made using the
adapter set WEM-CAN 2 wire (RF / RG1) (accessory).
Secure wall bracket1 to the wall using the screws supplied.
Feed the wires2 through and connect the plug to the wiring diagram.
Insert the lugs1 of the room device into the recesses2.
Click room device into place downwards.
