WEISS DAC204 User Manual

OPERATING INSTRUCTIONS FOR DAC204 24Bit / 192kHz D/A CONVERTER TECHNICAL DATA
Weiss Engineering Ltd., Florastr. 42, CH-8610 Uster, www.weiss.ch weiss@weiss.ch Page 7
Measurements:
The measurements below have been taken at the following conditions (unless noted otherwise): 1 kHz measurement frequency,
maximum selectable output level, 192kHz sampling frequency (Fs), 22kHz measurement bandwidth, unweighted, 0 dBr equals the
output level at 0 dBFS input.
FrequencyResponse
Fs = 44.1 kHz, 0Hz-20kHz: within +- 0.25dB
Fs = 88.2 kHz, 0Hz-20kHz: within +- 0.25dB
Fs = 88.2 kHz, 0Hz-40kHz: within +- 0.8dB
Fs = 176.4 kHz, 0Hz-20kHz: within +- 0.25dB
Fs = 176.4 kHz, 0Hz-40kHz: within +- 0.8dB
Fs = 176.4 kHz, 0Hz-80kHz: within +- 2.5dB
Total Harmonic Distortion plus Noise (THD+N)
−116 dBr (0.00016 %) at −3 dBFS input level
−125 dBr (0.000056 %) at −40 dBFS input level
−125 dBr (0.000056 %) at −70 dBFS input level
Linearity
At 0 dBFS to −120 dBFS input level: less than ±0.4 dB deviation from ideal
Spurious components (including harmonics)
At 0 dBFS input level, maximum output level, 1 kHz, all components at less than −120 dBr
At 0 dBFS input level, maximum output level, 4 kHz, all components at less than −115 dBr
Crosstalk
Better than 120 dB, 20 Hz–20 kHz
Interchannel Phase Response
+- 0.05° 20 Hz–20 kHz
+- 0.30° 20 Hz–80 kHz

WEISS DAC204 Specifications

General

Brand	WEISS
Model	DAC204
Category	Media Converter
Language	English
