OPERATING INSTRUCTIONS FOR DAC204 24Bit / 192kHz D/A CONVERTER TECHNICAL DATA
Weiss Engineering Ltd., Florastr. 42, CH-8610 Uster, www.weiss.ch weiss@weiss.ch Page 6
TECHNICAL DATA
Digital Inputs:
(1) RCA connector, (1) Toslink connector (optical)
- All inputs accept professional or consumer standard , i.e. accept AES/EBU or S/PDIF signals.
- Sampling frequencies: 44.1, 48.0, 88.2, 96.0, 176.4 or 192 kHz on the RCA input.
- Sampling frequencies: 44.1, 48.0, 88.2, 96.0 kHz on the Toslink input.
- Maximum input word-length: 24 Bits.
(1) USB connector
- Accepted sampling frequencies: 44.1, 48.0, 88.2, 96.0, 176.4, 192, 352.8, 384 kHz, DSD64, DSD128
Analog Outputs:
(2) XLR connectors (hot output on pin 2, not servo controlled), DC coupled, short circuit proof output circuitry, Output impedance: 44 Ohm
(2) RCA connectors, DC coupled, short circuit proof output circuitry, Output impedance: 22 Ohm
Output level: Selectable by two toggle switches, 4 settings:
XLR outputs:
7.5 Vrms, +19.7 dBu, with a 0 dBFS sinewave input
2.3 Vrms, +9.7 dBu, with a 0 dBFS sinewave input
0.75 Vrms, -0.3 dBu, with a 0 dBFS sinewave input
0.23 Vrms, -10.3 dBu, with a 0 dBFS sinewave input
RCA outputs:
3.75 Vrms, +13.7dBu, with a 0 dBFS sinewave input
1.15 Vrms, +3.7dBu, with a 0 dBFS sinewave input
0.375 Vrms, -6.3dBu, with a 0 dBFS sinewave input
0.115 Vrms, -16.3dBu, with a 0 dBFS sinewave input
Digital Outputs:
(1) XLR connector, (1) RCA connector, (1) BNC connector
Synchronization:
- Synchronized via the input signal in the case of RCA or Toslink inputs. In the USB input case the DAC204 is the master clock.
- Extremely efficient Jitter attenuation.
- Sampling frequencies supported: 44.1 kHz, 48.0 kHz, 88.2kHz, 96.0kHz, 176.4khz, 192kHz, 352.8kHz, 384kHz, DSD64, DSD128
Power:
- DC input voltage: 6 to 9 Volt
- DC input current: 1050mA at 6V, 700mA at 9V
- Power consumption: 6.3 W
