5. Instructions for use
For initial heating, coat the selective tinnable tip with sol-
der. This removes any oxidation or dirt on the tip which
may have occurred during storage. During pauses bet-
ween soldering and before storing the soldering iron,
ensure that the tip of the soldering iron is well coated. Do
not use aggressive fluxing agents.
Note: Always ensure the proper position of the solde-
ring iron tip.
These soldering irons have been adjusted for an average-
size tip. Deviations can occur due to exchanging of the tip
or using other tip designs.
If the total output of the unit is exceeded due to the con-
nected soldering tools the right channel will switch off
automatically.
External input unit WCB 1 and WCB 2 (optional)
The following functions are possible when using an
external input unit.
Offset: The real temperature of the soldering iron
can be changed by ± 40°C by input of a
temperature offset.
Setback: Reduction of the setpoint temperature to
150°C (standby). The setback time can be
set at 0-99 minutes after the soldering sta
tion has switched to standby mode. After a
period equal to three times the set-back
time, the ”Auto Off” function is activated.
The soldering iron is switched off (flashing
dash on the display).
Lock: Locking the setpoint temperature. Settings
cannot be changed after the soldering sta
tion has been locked.
°C/°F: Switching the temperature display from °C
to °F, and vice versa.
Window: Limitation of the temperature range to
max. ± 99°C based on a locked temperatu
re resulting from the "LOCK” function. The
locked temperature represents the median
point of the adjustable temperature range.
Cal: Re-adjustment of the soldering station
(WCB 2 only).
6. Accessories
5 29 161 99 Soldering iron set WSP 80
5 33 131 99 Soldering iron set MPR 80
5 33 111 99 Soldering iron set MLR 21
5 33 112 99 Soldering iron set LR 21, antistatic
5 33 113 99 Soldering iron set LR 82
5 33 155 99 Soldering iron set WMP
5 33 133 99 Soldering iron set WTA 50
5 13 050 99 Reflow soldering unit EXIN 5
5 25 030 99 Thermal insulating unit WST 20
5 31 181 99 External input unit WCB 1
5 31 180 99 External input unit WCB 2
WPHT Stop and go iron stand (WMP)
WPH80T Stop and go iron stand (WSP 80)
7. Items Supplied
WSD 161
PUD 161 Control Unit
2 x WSP 80 Soldering Iron
2 x WPH Soldering Iron Holder
Mains Cable
Operating Instructions
Safety Information
Jack Plug (not USA)
WSL 2
PUD 161 Control Unit
1 x WSP 80 Soldering Iron
1 x WPH Soldering Iron Holder
1 x WMP Soldering Iron
1 x WPHM Soldering Iron Holder
Mains Cable
Operating Instructions
Safety Information
Jack Plug (not USA)
PUD 161
PUD 161 Control Unit
Mains Cable
Operating Instructions
Safety Information
Jack Plug (not USA)
Circuit diagram - see page 75
Exploded diagram - see page 76/77
Subject to technical alterations and amendments!
