Thank You for purchasing this Wells Bloomfield appliance.
Proper installation, professional operation and consistent maintenance of this appliance will ensure that it
gives you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this appliance, and to use and care for the
appliance in a manner which will ensure its optimum performance.
TABLE OF CONTENTS
SPECIFICATIONS
INTRODUCTION
1
MODEL VOLTS AMPS WATTS POWER SUPPLY CORD
F-14
120 VAC 1ø 15A 1.8KW NEMA 5-15P
208/240 VAC 1ø 16.4/18.8A 3.4/4.5KW
NEMA 6-30P
F-49
208 VAC 1ø 22.1 A 4.6KW
NEMA 6-30P
208/240 VAC 1ø 16.6/19.1A 3.5/4.6KW
F-55
208VAC 1ø 27.7A 5.75KW
NOT SUPPLIED
240VAC 1ø 24.0A 5.75KW
F-67
208VAC 3ø
L1=38.3A
L2=22.1A
L3=22.1A
9.2KW
NOT SUPPLIED
208/240VAC 3ø
L1=28.8/33.2A
L2=16.6/19.2A
L3=16.6/19.2A
6.9/9.2KW
F-85
208VAC 3ø
L1=31.9A
L2=31.9A
L3=31.9A
11.5KW
NOT SUPPLIED 240VAC 3ø
L1=27.6A
L2=27.6A
L3=27.6A
11.5KW
480VAC 3ø
L1=13.8A
L2=13.8A
L3=13.8A
11.5KW
F-1725
208VAC 3ø
L1=47.8A
L2=47.8A
L3=47.8A
17.25KW
240VAC 3ø
L1=41.5A
L2=41.5A
L3=41.5A
17.25KW
NOT SUPPLIED
