WIRING DIAGRAM
18
301 p/n 2M-307588 Owners Manual Counter Top Standard Electric Fryers
HEATING
ELEMENT
CONTROL
THERMOSTAT
HI-LIMIT
THERMO
TEMP
LITE
WIRING DIAGRAM F-14 p/n 307306
SIGNAL
LITE
RELAY
HI-LIMIT
THERMO
VOLTS
(50/60 HZ)
AMPS
1 PHASE
240
208
120
16.3
18.8
15.0
FRYER F-14
COIL
C
NO
WIRE NUT
WIRE NUT
POWER CORD
HEATING
ELEMENT
CONTROL
THERMOSTAT
HI-LIMIT
THERMO
TEMP
LITE
WIRING DIAGRAM F-49 p/n 307298
SIGNAL
LITE
RELAY
HI-LIMIT
THERMO
VOLTS
(50/60 HZ)
AMPS
1 PHASE
240
208
208
16.6
19.1
22.1
FRYER F-49
COIL
C
NO
WIRE NUT
WIRE NUT
WIRE NUT
POWER CORD
208/240
