Wells F-49 - Page 23

301 p/n 2M-307588 Owners Manual Counter Top Standard Electric Fryers
WIRING DIAGRAM
19
HEATING
ELEMENT
CONTROL
THERMOSTAT
HI-LIMIT
THERMO
TEMP
LITE
WIRING DIAGRAM F-55 and F-556 p/n 307309
SIGNAL
LITE
RELAY
HI-LIMIT
THERMO
VOLTS
(50/60 HZ)
AMPS
1 PHASE
240
208
24.0
27.6
FRYER F-55 and F-556
COIL
C
NO
WIRE NUT
L1
L2
WIRE NUT
TERMINAL BLOCK
FLAME SENSOR
TERMINAL BLOCK
REMOVE JUMPER WHEN
EXTERNAL CONTROL USED
DO NOT CONNECT ANY POWER TO
FLAME SENSOR TERMINAL BLOCK
IMPORTANT:
