WIRING DIAGRAM
20
301 p/n 2M-307588 Owners Manual Counter Top Standard Electric Fryers
HEATING
ELEMENT
HEATING
ELEMENT
CONTROL
THERMOSTAT
CONTROL
THERMOSTAT
HI-LIMIT
THERMO
HI-LIMIT
THERMO
TEMP
LITE
TEMP
LITE
WIRING DIAGRAM F-67 and F-676 p/n 307302
SIGNAL
LITE
SIGNAL
LITE
RELAY
HI-LIMIT
THERMO
RELAY
HI-LIMIT
THERMO
VOLTS
(50/60 HZ)
VOLTS
(50/60 HZ)
AMPS
1 PHASE
AMPS 3 PHASE
240
240
208
208
208
208
38.3
44.2
33.2
FRYER F-67 and F-676
COIL COIL
CC
NO NO
WIRE
NUT
WIRE
NUT
L1 L1
L3 L3
L2 L2
WIRE
NUT
WIRE
NUT
TERMINAL BLOCK
(3 PHASE)
TERMINAL BLOCK
(1 PHASE)
1 1
2
2
1 1
2
2
L1 L2 L3
208/240V
208/
240V
28.8
33.2
38.3
16.6
19.2
22.1
16.6
19.2
22.1
