IDENTIFICATION CHART - THERMOSTATS AND CONTROL KNOBS
SV301 Service Manual Standard Fryers
7
GENERAL
(WELLS)
WELLS
Fryer F-14( F-49, F-67LLF-14),
54066
KNOB, TEMPERATURE CONTROL
THERMOSTAT
OFF (Bottom): 225ºF - 375ºF
Gray Plastic Knob / SS Skirt / Black Markings
Brushed Aluminum Center Insert
OFF
375
325
275
225
2.38”
1.13”
Æ.25” x .19”
(WELLS)
Fryer F-55, F-85
55511
KNOB, TEMPERATURE CONTROL
THERMOSTAT
OFF (Bottom): 300ºF - 375ºF
Gray Plastic Knob / SS Skirt / Black Markings
Brushed Aluminum Center Insert
WELLS
OFF
300
325
350
375
2.38”
1.13”
Æ.25” x .19”
50133
THERMOSTATIC SWITCH
DPST - OPEN ON RISE
TEMP CONTROL
OFF - 200ºF TO 375ºF
30AMP 240V
CAPILLARY & BULB
F-14(LLF-14), F-49, F-55, F-67
20
5.75
2.88
1.83
.81
1.55
.25 DIA
SHAFT
.38 DIA
BULB
8-32
SCREW
TERMINAL
(4 PLACES)
COM1
NC1
COM2
NC2
T
7/16-28
FERRULE
55510
THERMOSTATIC SWITCH
SPST - OPEN ON RISE
TEMP CONTROL
OFF - 300ºF TO 375ºF
30AMP 240V
CAPILLARY & BULB
F-55, F-85
36
8.50
2.88
1.66
.81
1.55
.25 DIA
SHAFT
.25 DIA
BULB
8-32
SCREW
TERMINAL
(2 PLACES)
COM1
NC1
T
7/16-28
FERRULE
58656
THERMOSTATIC SWITCH
SPST - OPEN ON RISE
HI-LIMIT SAFETY w/
MANUAL RESET
440ºF ±15ºF 30AMP 240V
CAPILLARY & BULB
F-14(LLF-14), F-49, F-55,
F-67, F-85
24
5.0
2.13
2.16
1.44
.25 DIA
BULB
8-32
SCREW
TERMINAL
(2 PLACES)
7/16-28
FERRULE
COM1
NC1
T
PUSH-BUTTON
RESET (RED)
FISH PAPER
INSULATOR
RESET
