Wen 10711 User Manual

Problem Possible Cause Solution
Incorrect
measurement
1. Measuring device improperly
fastened
1. Refer to the "OPERATION"
section for xing instructions,
and read the user's manual of
the measuring device being
used
Base will not
magnetize
1. Surface is not suitable
2. Magnet deteriorated from
improper use or storage
1. Clean surface; surface coating
is too thick; use surface that
can be magnetized
2. Magnet is permanently
damaged
Magnetic Force
176 lbf (782 N)
Clamping Hole
3/8" (9.53 mm)
Base
2-1/2" x 2" x 2-1/8"
63.5 mm x 50.8 mm x 54 mm
Height (Base to top of pole)
9-1/8"
Dial
Indicator
Lug
Clamp
Knob
Support
Rod Insert
Indicator
Mount Hole
Support
Rod Insert
Clamp
Knob
Indicator
Mount Hole
Dial
Indicator
Nut
Washer
Thread
Lug
Dial
Indicator

Wen 10711 Specifications

General

Brand	Wen
Model	10711
Category	Tools
Language	English
