Wen 31110 User Manual

ASSEMBLY & ADJUSTMENTS
MOUNTING THE PLATFORM
1. Lay the plywood platform (Fig. 4 - 1) over the flange pins that
extend up from the side rails and into the oblong holes cut in the
wood platform. These flange pins must fit properly.
2. Secure the platform in place with the platform hold-downs (Fig.
4 - 2).
3. Rotate the platform clips into the engaged position, as indicated
in Fig. 5.
4. If needed, a second scaffold (sold separately) must be assem-
bled by using the first scaffold as a stable platform. Refer to the
next page for attaching a second scaffold.
Use additional safety devices such as guard rails, mid rails and toe
boards to stabilize the second scaffold.
Fig. 4
1
2
Fig. 5
9
