No. Part No. Description Qty.
1 33606-001 Laser Button 1
2 33606-002 Laser Assembly 1
3 33606-003 Steel Wire Protection 1
4 33606-004
Reciprocating Screw
Positioning Plate
1
5 33606-005 Ball Slide 1
6 33606-006 Tool Reset Spring 1
7 33606-007
Reciprocating Lever
Assembly
1
8 33606-008 Shaft Sleeve 1
9 33606-009 Needle Roller Set 1
10 33606-010 Gear Assembly 1
11 33606-011 Cylindrical Roller 4
12 33606-012 Decorative Covers 1
13 33606-013 Laser Positioning Spring 1
14 33606-014 Dust-proof Piece 1
15 33606-015 Oil Baffle Gasket 1
16 33606-016 Oil Pad 1
17 33606-017 Screw ST4x30 2
18 33606-018 Rotor 1
19 33606-019 Carbon Brush 2
20 33606-020 Brush Holder 2
21 33606-021 Screw ST4x25 1
22 33606-022 Screw ST4x16 12
23 33606-023 Stator 1
24 33606-024 Dust Port Adapter 1
25 33606-025
Speed Control Board
Module
1
26 33606-026 Left Housing 1
27 33606-027 Switch 1
28 33606-028 Terminal 1
29 33606-029 Cable Clamp 1
30 33606-030 Cable Sheath 1
No. Part No. Description Qty.
31 33606-031 Power Cord 1
32 33606-032 Power Indicator Module 1
33 33606-033
Power Indicator Module
Cover
1
34 33606-034 Hex Wrench, 3mm 1
36 33606-036 Screw ST4x12 1
37 33606-037 Sealing Column 1
38 33606-038 Transparent Blade Guard 1
39 33606-039 Orbital Adjustment Shaft 1
40 33606-040 Ball 4 1
41 33606-041 Knob Positioning Spring 1
42 33606-042 Blade Orbit Selector 1
43 33606-043
Tool Support Reset
Torsion Spring
1
44 33606-044
Tool Support Positioning
Small Shaft
1
45 33606-045 Tool Support Module 1
46 33606-046 Parallel Guide Fence 1
47 33606-047 Air Deflector 1
48 33606-048
Vacuum Blower
Push Button
1
49 33606-049
Bottom Plate
Positioning Plate
1
50 33606-050
Guide Fence
Locking Knob
2
51 33606-051
Aluminum Base
Component
1
52 33606-052 Bottom Plate 1
53 33606-053 Screw M4x16 2
54 33606-054 Base Sheath 1
55 33606-055 Right Housing 1
N.P. 33606BW Wood Blade 1
N.P. 33606BM Metal Blade 1
NOTE: Parts that wear down over the course of normal use (like saw blades, carbon brushes, etc.)
are not covered by the two-year warranty.
EXPLODED VIEW & PARTS LIST
