Wen 3410 User Manual

Air Filtration System Model: 3410 WENPRODUCTS.COM
13
Exploded view and parts list (continued)
Item#
Part #
Description
Qty
Item#
Part #
Description
Qty
1
90243-001
Hex Nut 4
13
39
90243-039
Fuse Holder
1
2
90243-002
Flat Washer 4
13
40
90243-040
Fuse Cap
1
3
90243-003
Lock Washer 4
13
41
90243-041
Fuse (2A)
1
4
90243-004
Screw M4X12
5
42
90243-042
Control Panel Label
1
5
90243-005
Screw M6X16
6
43
90243-043
Screw M3X15
1
6
90243-006
Air Box Front Cover
1
44
90243-044
Screw M3X30
1
7
90243-007
Grid Plate
1
45
90243-045
Screw ST3.2X8
1
8
90243-008
Air Guide
1
46
90243-046
Printed Circuit Board
1
9
90243-009
Hex Nut 6
6
47
90243-047
Switch Box
1
10
90243-010
Flat Washer 6
6
48
90243-048
Flat Washer 3
2
11
90243-011
Lock Washer 6
6
49
90243-049
Lock Washer 3
2
12
90243-012
Screw M4X12
8
50
90243-050
Hex Nut 3
2
13
90243-013
Screw ST4X10
34
51
90243-051
Wire
1
14
90243-014
Air Box
1
As02
90243-AS02
Motor & Fan Assembly
1
15
90243-015
Screw M6X12
4
52
90243-052
Fan Wheel
1
16
90243-016
Carrying Handle
1
53
90243-053
Fan Housing Cover
1
17
90243-017
Handle Bracket
1
54
90243-054
Fan Housing
1
18
90243-018
Screw M5X16
2
55
90243-055
Rubber Spacer
4
19
90243-019
Flat Washer 5
3
56
90243-056
Large Washer 5
4
20
90243-020
Lock Washer 5
3
57
90243-057
Lock Nut 5
4
21
90243-021
Hex Nut 5
6
58
90243-058
Motor
1
22
90243-022
Screw M5X12
1
59
90243-059
Capacitor Cover
1
23
90243-023
Lock Washer 5
2
60
90243-060
Capacitor
1
24
90243-024
Wire
1
61
90243-061
Fan Housing Cover
1
25
90243-025
Grid Plate
1
62
90243-062
Screw M5X25
4
26
90243-026
Inner Filter
1
63
90243-063
Hanger
4
27
90243-027
Outer Filter
1
64
90243-064
Flange Nut 6
4
28
90243-028
Rubber Foot
4
65
90243-065
Chain
4
29
90243-029
Remote Control Unit
1
69
90243-069
Switch Box Cover
1
As01
90243-AS01
Control Panel Assembly
1
72
90243-072
Wood Screw Hook
4
36
90243-036
Power Cord
1
37
90243-037
Strain Relief
1
38
90243-038
Screw M5X20
1
