Wen 4015 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 4015-0001
Power Cord
Assembly
1
1-1 4015-0101 Power Line 1
1-2 4015-0102 Copper Strip 1
2 4015-0002 Cable Sleeve 1
3 4015-0003 Pan Head Screw 4
4 4015-0004 Cable Clamp 1
5 4015-0005 Connector 2
6 4015-0006 Micro-switch 1
7 4015-0007 Lock-off Button 1
8 4015-0008 Button Spring 1
9 4015-0009
Anti-Lock Button
Spring
1
10 4015-0010 Switch Button 1
11 4015-0011
Oil Box Cap
Assembly
1
11-1 4015-1101 Oil Box Cap 1
11-2 4015-1102 Seal Ring 1
11-3 4015-1103 Hanger 1
12 4015-0012 Swob 1
13 4015-0013 Oil Box Assembly 1
13-1 4015-1301 Oil Tank 1
13-2 4015-1302 Valve 1
13-3 4015-1303 Seal Ring 1
13-4 4015-1304 Transparent Oil Tube 1
13-5 4015-1305 Filtrate Spring 1
14 4015-0014
Flange Tapping
Screw
3
15 4015-0015 Oil Pump Assembly 1
15-1 4015-1501 Oil Pump Body 1
15-2 4015-1502 Worm Gear 1
15-3 4015-1503 Worm Gear Tooth 1
16 4015-0016 Cover 1
17 4015-0017 Self-tapping Screw 15
18 4015-0018 Motor Assembly 1
18-1 4015-1801 Hex Nut 2
18-2 4015-1802 Washer 2
18-3 4015-1803 Brush 2
18-4 4015-1804 Brush Holder 2
No. Part No. Description Qty.
18-5 4015-1805
Carbon Brush
Pressing Plate
2
18-6 4015-1806 Self-tapping Screw 4
18-7 4015-1807 Motor Back Support 1
18-8 4015-1808 Stator 1
18-9 4015-1809 Wind Screen 1
18-10 4015-1810 Flat Gasket 2
18-11 4015-1811 Sprng Washer 2
18-12 4015-1812 Stator Screw 2
18-13 4015-1813
The Rotor
Component
1
18-11-1 4015-1811-1 Bearing 1
18-11-2 4015-1811-2 Rotor Assembly 1
18-11-3 4015-1811-3 Bearing 1
18-14 4015-1814 Small Gear 1
18-15 4015-1815 Flanged Hex Nut 1
18-16 4015-1816 Connecting Wire 2
19 4015-0019
Lef Housing
Assembly
1
19-1 4015-1901 Front Handle 1
19-2 4015-1902 Pan Head Screw 1
19-3 4015-1903 Shield 1
19-4 4015-1904 Housing 1
19-5 4015-1905 Brake Washer 11
19-6 4015-1906 Pan Head Screw 11
20 4015-0020 Self-tapping Screw 4
21 4015-0021 Tubing Set Spring 1
22 4015-0022 Transparent Oil Tube 1
23 4015-0023
Oil Outlet Connector
Seat Asmbly.
1
23-1 4015-2301 Oil Outlet Joint Seat 1
23-2 4015-2302 Rubber Ring 2
24 4015-0024
Output Shaft
Assembly
1
24-1 4015-2401 Bearing 1
24-2 4015-2402 Big Gear 1
24-3 4015-2403 Output Shaft 1
24-4 4015-2404 Bearing 1
25 4015-0025 Connecting Wire 1
26 4015-0026 Connecting Wire 1
20

Wen 4015 Specifications

General

Brand	Wen
Model	4015
Category	Chainsaw
Language	English
