EXPLODED VIEW & PARTS LIST
HANDLE EXTENSION
NO. PART NO. DESCRIPTION QTY.
1 4019-101 Left Housing 1
2 4019-102 Screw ST4*16 11
3 4019-103 Bearing 6900 2
4 4019-104 Cam 1
5 4019-105 Output Gear 1
6 4019-106 Oil Pump Module 1
7 4019-107 Oil Can Module 1
8 4019-108 Rubber Stopper 1
9 4019-109 Outlet Tube 1
10 4019-110 Chain Saw Output Shaft 1
11 4019-111 Baffle Ring M10 1
12 4019-112 Oil Pad 1
13 4019-113 Screw ST3*8 1
14 4019-114 Screw M8 1
15 4019-115 Tubing Bend 1
16 4019-116 Guide Oil Seal 1
17 4019-117 Guide Bar 1
18 4019-118 Saw Chain 1
19 4019-119 Lock Knob 1
NO. PART NO. DESCRIPTION QTY.
20 4019-120 Tension Knob 1
21 4019-121 Guide Bar Cover 1
22 4019-122 Baffle Ring M18 1
23 4019-123 Tensioning Nut 1
24 4019-124 Tensioning Screw 1
25 4019-125 Tensioning Gear Cover 1
26 4019-126 Guide Bar Cover Gasket 1
27 4019-127 Chain Wheel 1
28 4019-128 Right Housing 7
29 4019-129 Brush Holder 2
30 4019-130 Copper Sheath 2
31 4019-131 Carbon Brush 2
32 4019-132 Stator 1
33 4019-133 Rotor 1
34 4019-134 Fastener 1
35 4019-135 Pin 5*20 1
36 4019-136 Insert Block 1
37 4019-137 Male Insert 2
NOTE: Not all parts may be available for purchase.
NOTE: Wear-and-tear parts (including but not limited to blades, chains, and carbon brushes) are not covered
under the warranty.
