EXPLODED VIEW AND PARTS LIST
No. GLT Part Number Part Name Description Qty
1
4021-001
Power Cord 1
2
4021-002
Cable Sheath 1
3
4021-003
Power Cord Screws 7
4
4021-004
Cable Clamp 3
5
4021-005
Switch Trigger 1
6
4021-006
Brake Lever Spring 1
7
4021-007
Button Spring 1
8
4021-008
Lock Off Button 1
9
4021-009
Control Switch 1
10
4021-010
Left Rear Handle 1
11
4021-011
Spring 1
12
4021-012
Left Sprocket 1
13
4021-013
Front Handle Screw 2
14
4021-014
Left Front Handle 1
15
4021-015
Right Front Handle Cover 1
16
4021-016
Handle Connection Screw 2
17
4021-017
Right Sprocket 1
18
4021-018
Right Rear Handle 1
19
4021-019
Self Tapping Screw 11
20
4021-020
Female Terminal 1
21
4021-021
Male Terminal 1
22
4021-022
Heat Shrink Sleeve For Female End 1
23
4021-023
Heat Shrink Sleeve For Male End 1
24
4021-024
The Spring Connecting Line 1
25
4021-025
Telescoping Clamp Sub Assembly 1
25-1
4021-026
Brace 1
25-2
4021-027
Nut 1
25-3
4021-028
Clamp Screw 1
25-4
4021-029
Clamp Ring 1
26
4021-030
Telescoping Subassembly 1
26-1
4021-031
Inner Pipe 1
26-2
4021-032
Plastic Hex Nuts 1
26-3
4021-033
Flat Washer 1
26-4
4021-034
Flat Gasket 1
26-5
4021-035
Machine Screw 1
26-6
4021-036
Cylindrical Pin 1
26-7
4021-037
Telescope Clamp 1
26-8
4021-038
Adjusting Bolt 1
26-9
4021-039
Lock Nut 1
26-10
4021-040
Telescope Sleeve 2
26-11
4021-041
Pin 1
26-12
4021-042
Ring 1
26-13
4021-043
Outer Telescoping Pipe 1
27
4021-044
Carbon Brush The Connecting Line 2
28
4021-045
607 Bearing 1
29
4021-046
Stator 1
30
4021-047
Bearing Bracket 1
31
4021-048
Clamp 2
32
4021-049
Flange Tapping Screw 4
33
4021-050
Brush Holder 2
34
4021-051
Carbon Brush 2
35
4021-052
Rotor Subassembly 1
36
4021-053
Deep Groove Ball Bearing 1
37
4021-054
Bearing Bracket 1
38
4021-055
Small Gear 1
39
4021-056
Hex Nut 1
No. GLT Part Number Part Name Description Qty
40
4021-057
Left Housing 1
41
4021-058
Oil Pump Sub Assembly 1
41-1
4021-059
Oil Pump Tension Spring 1
41-2
4021-060
Oil Pump 1
41-3
4021-061
Worm Gear 1
41-4
4021-062
Worm Gear End 1
42
4021-063
Gear Sub Assembly 1
42-1
4021-064
Bearing 1
42-2
4021-065
Split Washer 1
42-3
4021-066
Big Gear 1
42-4
4021-067
Output Shaft 1
42-5
4021-068
Woodruff Key 1
42-6
4021-069
Bearing 1
43
4021-070
O Ring 2
44
4021-071
Oil Nozzle 1
45
4021-072
Oil Hosing 1
46
4021-073
Right Housing 1
47
4021-074
Right Housing Screw 2
48
4021-075
Housing Screws 8
49
4021-076
Dust Cover Screw 1
50
4021-077
Flat Gasket 1
51
4021-078
The Dustproof Cover 1
52
4021-079
Heat Insulation Plate 1
53
4021-080
Heat Plate Screws 2
54
4021-081
Cover Screws 1
55
4021-082
Oil-Out Seal Ring 1
56
4021-083
Sprocket 1
57
4021-084
Retaining Ring 1
58
4021-085
Adjustment Sub Assembly 1
58-1
4021-086
Retaining Ring 1
58-2
4021-087
Adjustment Cover 1
58-3
4021-088
Adjusting Knob 1
58-4
4021-089
Knob 1
59
4021-090
Oil Tank Cap Sub Assembly 1
59-1
4021-091
Oil Tank Cap 1
59-2
4021-092
Oil Tank O Ring 1
59-3
4021-093
Anti Drop Hook 1
60
4021-094
Oil Tank Sub Assembly 1
60-1
4021-095
Oil Tank 1
60-2
4021-096
Valve 1
60-3
4021-097
Filtrate Spring 1
60-4
4021-098
O Ring 1
60-5
4021-099
Hosing 1
60-6
4021-100
Tube Spring 1
61
4021-101
Chain Bar Subassembly 1
61-1
4021-102
Bar Screw 1
61-2
4021-103
Seal Ring 1
61-3
4021-104
Chain Bar 1
61-4
4021-105
U Gear 1
62
4021-106
Chain Blade 1
63
4021-107
Guide Bar Sleeve 1
64
4021-108
Auxiliary Handle Subassembly 1
64-1
4021-109
Auxiliary Handle 1
64-2
4021-110
Auxiliary Handle Bracket 1
64-3
4021-111
Screw 4
64-4
4021-112
Nut 4
