BATTERY
1. Make sure the battery is fully charged before storage in order to maximize the life of the battery.
2. Do not store the battery pack on the tool.
3. After charging, the battery pack may be stored in the charger, as long as the charger is not plugged in.
CHARGER
1. Keep the charger clean and clear of debris. Do not allow foreign material to get into the recessed cavity or onto
the contacts. Wipe the charger clean with a dry cloth. Do not use solvents or water, and do not place the charger in
wet conditions.
2. Unplug the charger when there is no battery in it.
3. Fully charge the battery before placing it in storage.
4. Store the charger at normal room temperature. Do not store it in excessive heat. Do not use the charger in direct
sunlight or in damp conditions. Do not charge outside. Recharge at room temperature. If the battery is hot, allow it
to cool down before recharging.
MAINTENANCE
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1
40401
40V Battery 1
2
40413-002
Screw 22
3
40413-003
Right Battery Housing 1
4
40413-004
PCB 1
5
40413-005
Trigger 1
6 40413-006 Base Plate 2
7 40413-007 Spring 1
8 40413-008 Left Battery Housing 1
9
40413-009
Battery Latch 1
10
40413-010
Pin 1
11
40413-011
Torsional Spring 1
12
40413-012
Shaft 1
13 40413-013 Spring 1
14 40413-014 Safety 1
15 40413-015 Cable Clamp 1
16
40413-016
Tube Assembly 1
17
40413-017
Wiring Harness 1
18
40413-018
Wire Casing 4
19
40413-019
Right Housing 1
20 40413-020 Left Housing 1
21 40413-021 Wire Frame 1
22 40413-022 Motor Assembly 1
23 40413-023 Flange 1
No. Part No. Description Qty.
24
40413-024
Screw 2
25 40413-025 Spindle 1
26
40413-026
Handle Assembly 1
26.1 Knob 1
26.2 Handle 1
26.3 Screw 1
27
40413-027
Debris Shield Assembly 1
27.1 Shield 1
27.2 Blade 1
27.3 Screw 2
27.4 Blade Guide 1
28 40413-028 Screw 1
29
40413-029
Cutter Head Assembly 1
29.1 Rivet 2
29.2 Head Housing 1
29.3 Seat 1
29.4 Spring 1
29.5 Skate 1
29.6 Cutting Wire 1
29.7 Spool 1
29.8 Gap 1
30 40400 Charger 1
