EXPLODED VIEW & PARTS LIST
No. Part No. Name Qty.
1 49103-001 Nameplate Sticker 1
2 49103-002 Screw 5
3 49103-003 Screw 4
4 49103-004 Right Housing 1
5 49103-005 Charger 1
6 49103-006 Screw 3
7 49103-007 Output Shaft 1
8 49103-008 Small Washer 3
9 49103-009 Steel Ball 12
10 49103-010 Shaft Sleeve 2
11 49103-011 Front Cover 1
12 49103-012 Outer Gear 2
13 49103-013 Clamp Spring 2
14 49103-014 Shaft Sleeve 2
15 49103-015 Central Shaft 1
16 49103-016 Gear Box 1
17 49103-017 Position Lock Block 1
18 49103-018 Screw 1
19 49103-019 Self-Lock Ring 1
20 49103-020 Inner Gear 1
21 49103-021 Self-Lock Pin 2
22 49103-022 Shaft Plate 1
23 49103-023 Planet Gear 3
24 49103-024 Central Shaft Plate 1
25 49103-025 Plastic Planet Gear 3
26 49103-026 Big Washer 1
27 49103-027 Motor Gear 1
28 49103-028 Pin 2
29 49103-029 Gear Box Rear Cover 1
30 49103-030 Motor 1
31 49103-031 3.6V Li-Ion Battery 1
32 49103-032 Switch Control Set 1
33 49103-033 Left Housing Set 1
34 49103-034 Safety and Direction Switch 1
35 49103-035 Trigger Plate 1
