Wen 61764 User Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description
1 61764-001 Screw
2 61764-002 Spring Washer
3 61764-003 Bushing
4 61764-004 Exhaust Cover
5 61764-005 Washer
6 61764-006 Screw
7 61764-007 Cylinder Cap
8 61764-008 Seal
9 61764-009 Gasket
10 61764-010 Spring
11 61764-011 O=Ring (22.8x2.5)
12 61764-012 O-Ring (49.2x3.5)
13 61764-013 Valve
14 61764-014 O-Ring (28.3x3)
15 61764-015 O-Ring (43.3x3.5)
17 61764-017 O-Ring (40.3x3.5)
18 61764-018 Piston Assembly
19 61764-019 Collar
20 61764-020 Cylinder
21 61764-021 O-Ring (66.6x2.6)
22 61764-022 Sealed Ring
23 61764-023 O-Ring (66.6x2.6)
25 61764-025 Bumper
26 61764-026 Body
27 61764-027 Safe Guider
28 61764-028 Spring
29 61764-029 Safe Bracket A
30 61764-030 Ball
31 61764-031 Spring
32 61764-032 Adjusting Nut
33 61764-033 Lock Washer
34 61764-034 Pin
35 61764-035 Safe Bracket
36 61764-036 latch Assembly
37 61764-037 O-Ring (20.3x2.5)
38 61764-038 O-Ring (20.3x1.5)
39 61764-039 Valve Guider
40 61764-040 Trigger Valve Guider
41 61764-041 Spring Pin
42 61764-042 Spring
43 61764-043 Washer
No. Part No. Description
44 61764-044 Trigger Assembly
45 61764-045 Pin
46 61764-046 O-Ring (9.5x1.9)
47 61764-047 O-Ring (10.3x1.9)
48 61764-048 O-Ring (12.8x1.9)
49 61764-049 Trigger Valve Head
50 61764-050 O-Ring (5.5x1.5)
51 61764-051 Spring
52 61764-052 Trigger Valve Stem
53 61764-053 Feeder Seat
55 61764-055 Spring Washer
57 61764-057 Screw
58 61764-058 Plate
59 61764-059 Rail
60 61764-060 Front Plate
61 61764-061 Pin
62 61764-062 Pin
63 61764-063 Screw
64 61764-064 Drive Guide
65 61764-065 Pin
66 61764-066 Movable Magazine
67 61764-067 Spring
68 61764-068 Lock
69 61764-069 Pin
70 61764-070 Feeder Shoe
71 61764-071 Spring
72 61764-072 Spring Seat
73 61764-073 Stopped Piece
74 61764-074 Stopped Plate
75 61764-075 Screw
76 61764-076 Block
77 61764-077 Fixed Magazine
78 61764-078 Screw
79 61764-079 Support
80 61764-080 Nut
81 61764-081 Spring Washer
82 61764-082 Soft Grip Sleeve
83 61764-083 O-Ring (48.8x2.5)
84 61764-084 End Cap
85 61764-085 Air Plug
15
