Wen 6552

EXPLODED VIEW AND PARTS LIST
16
Part Number Description Quantity Part Number Description Quantity
6552-001 Handle assembly 1 6552-061 Hex wrench 1
6552-002 Cap 1 6552-062 Magnet 2
6552-003 Socket head screw 1 6552-063 Spring 4
6552-004 Flat washer 1 6552-064 Bearing block 4
6552-005 Roller 2 6552-065 LH retainer 2
6552-006 Roller cap 4 6552-066 Flat washer 8
6552-007 Flat head screw 4 6552-067 Lock washer 8
6552-008 Top cover 1 6552-068 Socket head screw 8
6552-009 Grip 2 6552-069 Outfeed roller 1
6552-010 Flat head screw 4 6552-070 Rh retainer 2
6552-011 Left cover 2 6552-071 Infeed roller 1
6552-012 Retaining ring 3 6552-072 Power cord 1
6552-013 Chain 2 6552-073 Motor 1
6552-014 Sprocket 4 6552-074 Switch 1
6552-015 Socket head screw 4 6552-075 Circuit breaker 1
6552-016 Spacer 1 6552-076 Brush holder 2
6552-017 Gear box assembly 1 6552-077 Brush 2
6552-018 Pinion 1 6552-078 Brush cap 2
6552-019 Ball bearing 1 6552-079 Spacer 1
6552-020 Elevating nut (LH) 1 6552-080 Flat washer 1
6552-021 Hex nut 2 6552-081 Socket head screw 1
6552-022 Cable clamp 1 6552-082 Socket head screw 1
6552-023 Socket head screw 1 6552-083 Flat washer 1
6552-024 Chain cover 1 6552-084 Elevating screw (LH) 1
6552-025 Pan head screw 2 6552-085 Dust cover 2
6552-026 Lock washer 2 6552-086 Slide bearing 2
6552-027 Serrated washer 2 6552-087 Slide bearing housing 2
6552-028 Socket head screw 2 6552-088 Spacer 2
6552-029 Belt cover 1 6552-089 Flat washer 2
6552-030 Elevating nut (RH) 1 6552-090 Column 4
6552-031 Pan head screw 2 6552-091 Hex nut 4
6552-032 Pointer 1 6552-092 Guide 2
6552-033 Rollercase 1 6552-093 Table 1
6552-034 Motor pivot rod 1 6552-094 Socket head screw 8
6552-035 Rod clamp 2 6552-095 Flat washer 8
6552-036 Set screw 2 6552-096 Outfeed extension table 1
6552-037 Lock washer 4 6552-097 Flat washer 4
6552-038 Pan head screw 4 6552-098 Pan head screw 4
6552-039 Depth-of-cut gauge 1 6552-099 Hook 2
6552-040 Pan head screw 3 6552-100 Elevating screw (RH) 1
6552-041 Cutterhead 1 6552-101 Key 2
6552-042 Key 1 6552-102 Socket head screw 4
6552-043 Blade 3 6552-103 Lock washer 4
6552-044 Blade clamp 3 6552-104 Base 1
6552-045 Socket head screw 16 6552-105 Infeed extension table 1
6552-046 Ball bearing 1 6552-106 Bushing 4
6552-047 Bearing house 1 6552-107 Limiting plate A 2
6552-048 Pan head screw 3 6552-108 Flat washer 4
6552-049 Cutterhead pulley 1 6552-109 Lock washer 4
6552-050 Motor pulley 1 6552-110 Socket head screw 4
6552-051 Belt 1 6552-111 Limiting plate B 2
6552-052 Hex nut 1 6552-112 Hex head bolt 4
6552-053 Screw 2 6552-113 Hex nut 4
6552-054 Dust exhaust port 1 6552-114 Bevel gear 4
6552-055 Connecting port 1 6552-115 Nut 2
6552-056 Socket head screw 4 6552-116 Shaft 1
6552-057 Flat washer 4 6552-117 Key 2
6552-058 Dust chute 1 6552-118 Support 2
6552-059 Chute plate 1 6552-119 Socket head screw 4
6552-060 Flat head tap screw 4 6552-120 Retaining ring 2
