NOTE: Parts that wear down over the course of normal use (like accessories, carbon brushes, etc.) are not covered
by the two-year warranty. Repairs and replacements should only be performed by an authorized technician.
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 94475-001 Outer Flange 1
2 94475B Grinding Wheel 3
3 94475-003 Inner Flange 1
4 94475-004
Wheel Guard
(with Lock Screw)
1
5 94475-005 Key, 3X10x3.7 1
6 94475-006
Output Shaft, Φ20.5x67
1
7 94475-007
Screw With Washer,
M4x14
4
8 94475-008 Gear Box Cover 1
9 94475-009 Ball Bearing, 6201-Rs 1
10 94475-010
Retaining Ring, Φ32
1
11 94475-011
Output Gear,
Φ44.6×Φ12 (37T)
1
12 94475-012
Wavy Washer, Φ12
1
13 94475-013
Shaft Circlip, Φ12
1
14 94475-014
Bearing, Φ8×Φ12×8
1
15 94475-015 Support Handle 1
16 94475-016 Screw, ST4.2x16 4
17 94475-017 Gear Box Cover 1
18 94475-018 Spindle Lock Button 1
19 94475-019 Spring 1
20 94475-020 Washer 1
21 94475-021 Nut, M6x5 1
22 94475-022
Bevel Gear, Φ8×Φ15
(10T)
1
23 94475-023 Ball Bearing, 608-Rs 1
24 94475-024
Washer, Φ22
1
No. Part No. Description Qty.
25 94475-025
Rotor, Φ32x40mm
(1-9/16 inch)
1
26 94475-026 Ball Bearing, 607Zz 1
27 94475-027 Bearing Sleeve 1
28 94475-028 Motor Baffle 1
29 94475-029 Screw, ST4.2×50 2
30 94475-030
Stator,
Φ53x40mm(1-9/16 Inch)
1
31 94475-031 Front Housing 1
32 94475-032 Carbon Brush 2
33 94475-033 Screw, ST3x8 2
34 94475-034 Brush Holder 2
35 94475-035 Brush Spring 2
36 94475-036 Switch 1
37 94475-037 Screw, ST4.2x12 1
38 94475-038 Cord Clamp 1
39 94475-039 Spring 1
40 94475-040 Switch Trigger Lever 1
41 94475-041 Switch Trigger 1
42 94475-042 Cord Sleeve 1
43 94475-043 Rear Housing 1
44 94475-044 Screw, ST4.2x14 1
45 94475-045
Power Cord With Plug,
2m/6.5Feet
1
46 94475-046 Logo Label 1
47 94475-047 Rating Label 1
48 94475-048 Wrench 1
49 94475-049 Switch Holder 1
50 94475-050 Screw 1
51 94475-051 Square Nut 1
15
To Next Page
