ASSEMBLY & ADJUSTMENTS

ASSEMBLING THE HANDLE

1. Assemble the lower handles (Fig. 1 - 1) onto the dethatcher / scari-

ﬁer body as shown in Fig. 1. NOTE: There are three installation heights.

2. Assemble the handle angle adjustment knobs (Fig. 1 - 2) at the base

of each lower handle. Turn the angle adjustment knobs clockwise

to tighten the handles and counterclockwise to loosen the handles.

NOTE: Make sure that the lower handles are secure with the angle

adjustment knobs before operation.

3. Install the middle handle (Fig. 2 - 1) onto the two lower handles

using two handle knobs (Fig. 2 - 2) and two bolts (Fig. 2 - 3), one on

either side. NOTE: Make sure that the middle handle is installed on the

inside of the lower handles.

4. Install the upper handle (Fig. 3 - 1) onto the middle handle using

two handle knobs (Fig. 3 - 2) and two bolts, one on either side. NOTE:

Make sure that the upper handle is installed on the outside of the

middle handle and that the extension cord holder (Fig. 3 - 3) is on the

same side as the safety lock.

5. Slip the power cord (Fig. 3 - 4) through the cable clip (Fig. 3 - 5)

and secure the cable clip to the upper handle on the same side as the

extensions cord holder and safety lock.

WARNING! Make sure that the machine is OFF and disconnected from the power source before assembling

or making any adjustments.

Fig. 1

Fig. 2

Fig. 3

1 1

2 2

Wen DT1315 User Manual
