Wen DT1516

19
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DT1516-001 Front Hub Cap 2
2 DT1516-002 Front Wheel Pin 2
3 DT1516-003 Front Wheel Washer 2
4 DT1516-004 Front Wheel 2
5 DT1516-005 Front Axle Assembly 1
6 DT1516-006
Left Depth Adjustment
Handle
1
7 DT1516-007 Press Plate 2
8 DT1516-008
Right Depth Adjustment
Handle
1
9 DT1516-009 Rear Hub Cap 2
10 DT1516-010 Rear Wheel 2
11 DT1516-011 Rear Wheel Screw 2
12 DT1516-012 Rear Axle Rod 2
13 DT1516-013 Lock Nut 2
14 DT1516-014 Retaining Plate 1
15 DT1516-015 Self-Tapping Screw 9
16 DT1516-016 Air Filter Element #2 1
17 DT1516-017 Housing Screw 2
18 DT1516-018 Motor Bracket Screw 2
19 DT1516-019 Air Filter Element #1 1
20 DT1516-020 Motor Fan Housing 1
21 DT1516-021 Top Cover 1
22 DT1516-022 Grass Flap 1
23 DT1516-023 Panel Bracket 1
24 DT1516-024 Panel Insert 1
26 DT1516-026 Grass Flap Spring 1
NO. PART NO. DESCRIPTION QTY.
27 DT1516-027 Grass Flap Rod 1
28 DT1516-028 Depth Adjustment Plate 1
29 DT1516-029
Grass Collection Bag
Frame
1
30 DT1516-030 Handle Frame Nut M6 4
31 DT1516-031
Handle Frame Locking
Knob
4
32 DT1516-032 Locking Knob Washer 6
33 DT1516-033 Locking Knob Bolt 4
34 DT1315-049 Hex Wrench Clip 1
35 DT1315-046 Middle Handle Frame 1
36 DT1516-036 Lower Handle Frame Tube 2
37 DT1516-037 Lower Handle Screw 2
38 DT1516-038 Lower Locking Knob 2
39 DT1516-039 Pin 2
40 DT1516-040
Lower Handle Tube
Bracket
2
41 DT1516-041 Grass Collection Bag 1
42 DT1516-042 Main Machine Frame 2
43 DT1516-043 Dust Seal Plate 2
44 DT1516-044 Air Filter Element #3 1
45 DT1315-048 Power Cord Clip 1
46 DT1315-011 Press Plate 1
47 DT1516-047 Self-tapping Screw 2
48 DT1516-048 Fan Housing Screw 21
49 DT1315-031 Hex Wrench 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
BODY ASSEMBLY
