20
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 RT1460-001 BEARING SLEEVE 1
2 RT1460-002 BALL BEARING 627 1
3 RT1460-003 MAGNET SLEEVE 1
4 RT1460-004 ARMATURE 1
5 RT1460-005 RETAINING RING 17 1
6 RT1460-006 BALL BEARING 6003 1
7 RT1460-007 BEARING SLEEVE 1
8 RT1460-008 BRUSH HOLDER CAP 2
9 RT1460-009 BRUSH HOLDER 2
10 RT1460-010 CARBON BRUSH 2
11 RT1460-011 SWITCH 1
12 RT1460-012 TOP COVER 1
13 RT1460-013 PCB CONTROLLER 1
14 RT1460-014 TAPPING SCREW ST4x14 2
15 RT1460-015 STRAIN RELIEF 1
16 RT1460-016 CORD GUARD 1
17 RT1460-017 CORD 1
18 RT1460-018 BRACKET COMPLETE 1
19 RT1460-019 ROUND SPRING 2
20 RT1460-020 STATOR 1
21 RT1460-021 SCREW ST4x65 2
22 RT1460-022 HOUSING 1
23 RT1460-023 TAPPING SCREW ST4x55 4
24 RT1460-024 SPRING 6.5x0.8x16 1
25 RT1460-025 PUSH BUTTON 1
26 RT1460-026 THUMB SCREW 1
No. Part No. Description Qty.
27 RT1460-027 FLAT WASHER 6 3
28 RT1460-028 COLLET NUT 1
29 RT1460-029 COLLET CONE 6mm 1
30 RT1460-030 LOCK NUT M6 1
31 RT1460-031 LOCK SCREW 1
32 RT1460-032 PIN 4x4 1
33 RT1460-033
TRIMMER BASE
COMPLETE
1
34 RT1460-034 BASE PROTECTOR 1
35 RT1460-035 BOLT M4x12 4
36 RT1460-036 SPRING PIN 3x14 1
37 RT1460-037 LOCK LEVEL 1
38 RT1460-038
SQUAREWASHER
10x13x1
1
39 RT1460-039 WASHER 4 1
40 RT1460-040 SPUR GEAR 1
41 RT1460-041 PIN 1
42 RT1460-042 LOCK SCREW 1
43 RT1460-043 TRIMMER GUIDE 1
44 RT1460-044 BOLT M6x18 1
45 RT1460-045 STRAIGHT GUIDE 1
46 RT1460-046
STRAIGHT GUIDER
HOLDER
1
47 RT1460-047 BUTTERFLY NUT M6 1
49 RT1460-049 WRENCH, 13MM 1
50 RT1460-050 WRENCH, 22MM 1
