Wen TC0714

EXPLODED VIEW & PARTS LIST
18
NO. PART NO. DESCRIPTION QTY.
1 TC0714-001 Blade Shaft 1
2 TC0714-002 Gasket, Gearbox 1
3 TC0714-003 Gearbox Cover, Right 1
4 TC0714-004 Lock Nut, M8 2
5 TC0714-005 Blade Subassembly, Right 1
6 TC0714-006 Hex Screw, M8 2
7 TC0714-007 Carriage Bolt, M6x20 8
8 TC0714-008 Blade Guard 1
9 TC0714-009 Lower Housing Base 1
10 TC0714-010 Lock Nut, M6 8
11 TC0714-011 Splined Connector Sleeve 2
12 TC0714-012 Rotor Positioning Plate 1
13 TC0714-013 Ball Bearing, 6000 1
14 TC0714-014 Lower Motor Cover 1
15 TC0714-015 Rotor 1
16 TC0714-016 Screw, M5x80 2
17 TC0714-017 Spring Washer, 5mm 4
18 TC0714-018 Stator 1
19 TC0714-019 Ball Bearing, 608 2
20 TC0714-020 Thermal Breaker 1
21 TC0714-021 Wire Terminal 2
22 TC0714-022 Nut, M5 2
23 TC0714-023
Self-tapping Screw,
ST3x12
3
24 TC0714-024 Carbon Brush Holder 2
25 TC0714-025 Carbon Brush 2
26 TC0714-026 Upper Motor Cover 1
27 TC0714-027 Upper Housing 1
28 TC0714-028
Self-tapping Screw,
ST4x16
2
29 TC0714-029
Self-tapping Screw, Phil-
lips, ST4x16
39
30 TC0714-030 Power Cord Strain Relief 2
31 TC0714-031
Power Cord Clamping
Plate
3
32 TC0714-032 Upper Housing Cover 1
33 TC0714-033 Handle Base Plate 1
34 TC0714-034 Right Handle, Inner 1
35 TC0714-035 Safety Button 1
NO. PART NO. DESCRIPTION QTY.
36 TC0714-036 Safety Button Spring 1
37 TC0714-037 Switch Trigger 1
38 TC0714-038 Switch Trigger Spring 1
39 TC0714-039 Power Switch 1
40 TC0714-040 Right Handle, Outer 1
41 TC0714-041 Power Cord 1
42 TC0714-042 Wire 1
43 TC0714-043 Screw, M6x45 4
44 TC0714-044 Handle Frame, Middle 1
45 TC0714-045 Wire Clip 2
47 TC0714-047 Wavy Washer 1
48 TC0714-048 Frame Knob 4
49 TC0714-049
Handle Frame, Lower
Right
1
50 TC0714-050
Self-tapping Screw,
ST4x20
10
51 TC0714-051 Outer Damper Pad 1
52 TC0714-052 Inner Damper Pad 1
53 TC0714-053 Splined Connector Shaft 1
54 TC0714-054 Shaft Sealing Ring 1
56 TC0714-056 Ball Bearing, 6001 1
57 TC0714-057 Worm Gear 1
58 TC0714-058 Shaft Gear 1
59 TC0714-059 Key, 4x4x16mm 1
60 TC0714-060 Washer, 19mm 2
61 TC0714-061 Oil Bearing Block 2
62 TC0714-062 Gearbox Cover, Left 1
63 TC0714-063 Spring Washer, 6mm 8
64 TC0714-064
Socket Head Cap Screw,
M6x18
8
65 TC0714-065 O-ring 1
66 TC0714-066
Socket Head Cap Screw,
M10x10
1
67 TC0714-067 Gearbox Seal 2
68 TC0714-068 Gearbox Seal Cover 2
69 TC0714-069 Left Handle, Inner 1
70 TC0714-070 Handle Frame, Upper 1
71 TC0714-071 Left Handle, Outer 1
72 TC0714-072 Handle Frame, Lower Left 1
