EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 WB4723-001 Front Post 2
2 WB4723-002 Back Post 2
3 WB4723-003 Rubber Foot 4
4 WB4723-004 Side Beam 3
4A WB4723-004A Side Beam with Power Strip Opening 1
5 WB4723-005 Bottom Beam 2
6 WB4723-006 Top Beam 2
7F WB4723-007F Front Drawer Bracket 1
7B WB4723-007B Back Drawer Bracket 1
8 WB4723-008 Middle Drawer Mount 1
9L WB4723-009L Left Drawer Mount 1
9R WB4723-009R Right Drawer Mount 1
10L WB4723-010L Left Drawer Panel 2
10R WB4723-010R Right Drawer Panel 2
11 WB4723-011 Front Drawer Panel 2
12 WB4723-012 Back Drawer Panel 2
13 WB4723-013 Drawer Bottom 2
14 WB4723-014 Drawer Handle 2
15L WB4723-015L Left Back Upper Post 1
15R WB4723-015R Right Back Upper Post 1
16F WB4723-016F Front Shelf Beam 1
16B WB4723-016B Back Shelf Beam 1
17L WB4723-017L Left Shelf Beam 1
17R WB4723-017R Right Shelf Beam 1
18 WB4723-018 Pegboard 1
19 WB4723-019 Bench Top 1
20 WB4723-020 Bottom Shelf 1
21 WB4723-021 Top Shelf 1
22 WB4723-022 Power Strip (not shown) 1
23 WB4723-023 Light Fixture (not shown) 1
A WB4723-024 Bolt (M4x10), Washer, Nut (not shown) 8
B WB4723-025 Bolt (M6x10), Washer, Nut (not shown) 78
C WB4723-026 Bolt (M6x16), Washer, Nut (not shown) 13
D WB4723-027 Bolt (M5x25), Washer, Nut (not shown) 12
E WB4723-028 Screw (ST4x9.5) (not shown) 4
F WB4723-029 U Bracket (not shown) 2
G WB4723-030 Bolt (M4x16) (not shown) 2
Unpack and remove all parts from the box. Check all components and organize them according to the parts list
below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or
