11
Lowering the Shell
1.
Turn
the Crank
Handle ¼
turn
Clockwise to
slightly
raise the
Upper Panel.
2.
Push
out on
the bottom
of
the Middle
Panel to
separate
it from
the
magnets.
3.
Turn
the Crank
Handle counter-clockwise
until
the
shell
is completely
lowered.
Do not force the crank handle
or the crank mechanism
could be damaged.
!
CAUTION
The Middle Panel must be
disengaged before the shell
can be lowered.
!
CAUTION
Crank
Handle
Magnet
Upper
Panel
Magnet
10
12
