12
TOPITEC
®
TOUCH User Manual | 11-2020
2.3 Technical data
2.3.1 Product-specific data
Warning
The materials and media to be used for processing in the mixing system
are to be sourced by the device operator, who is responsible for the proper
use of these substances. The device operator is also responsible for the
correct handling of these materials / media, with due regard to any
associated risks. The device operator must provide hazard and disposal
instructions for staff. Always observe the information in the material
safety data sheets provided by the manufacturers of the materials / media.
For quality and safety reasons, only use original jars.
Jar sizes: Jars up to max. diameter 118 mm
Single-patient containers, single-patient jars, jars for stock preparation
2.3.2 Dimensions and weight
TOPITEC
®
TOUCH (device dimensions) including touch screen
Width: approx. 280 mm
Depth: approx. 280 mm
Height: approx. 710 mm
Total weight: approx. 18.5 kg
2.3.3 Power supply
Operating voltage: 1 x 230 V
AC
+ 6 %, -10 %
Phases: 1 Ph / PE
Protective earth conductor: separate PE (yellow/green)
Frequency: 50 Hz ± 1 %
Protection rating: I
Protection class: IP 20
Installation standard: DIN EN 61010-1: 2011
Power supply
Fuses: max. 2 x 10 A (slow-acting), sand-filled
Conductor cross-section: min. 1.5 mm
2
Cu
Rated power: max. 1,800 W
