DEVICE COMPONENTS AND PROPER USE
2.3.4 Load on tabletop
Weight including all media:
Static load: approx. 0.185 kN (18.5 kg)
Static + dynamic load: approx. 0.25 kN (25.0 kg)
2.3.5 General data
Operating temperature range:
Lower limit temperature: + 15° C
Upper limit temperature: + 35° C
Control cabinets / control devices: < 40° C
Air humidity: max. 80 %, non-condensing
Max. altitude: ≤ 2000 m above sea level
Storage conditions:
Lower limit temperature: + 5° C
Upper limit temperature: + 50° C
Air humidity: 10 - 80 %, non-condensing
Noise emission:
Sound pressure level:
(according to 2006/42/EC), measuring report: L
PA
= 52 - 62 dB
(A)
Measurement uncertainty (L
PA
) 2 dB
Recommended lighting:
(workplace lighting, to be provided by device owner,
according to ASR A3.4, chapter 7.6). Recommendation: E
x
= 300 lux
Inspection areas: E
x
= 500 lux
Colours:
TOPITEC
®
TOUCH: Pearl night blue, order no. 026620
TOPITEC
®
TOUCH: Pearl white, order no. 026621
TOPITEC
®
TOUCH: Pearl white, order no. 026622
Warning
Risk from lightning: The operator must provide preliminary and medium pro-
tection for the power supply. Depending on the lightning protection installed
on site, it might be necessary to install additional fine protection.
Recommended lighting:
(workplace lighting, to be provided by device owner,
according to ASR A3.4, chapter 7.6). Recommendation: E
x
= 500 lux
Inspection areas: E
x
= 500 lux
Colours:
TOPITEC
®
EXPERT 1: Pearl night blue, order no. 026720
TOPITEC
®
EXPERT 2: Pearl white, order no. 026721
Warning
The device must be connected to a safety socket. The device is equipped with a fine protection
fuse. Medium and general protection must be provided in the building’s distribution system.
The device is protected with two fuses (2x 10A (slow-acting) sand-filled) installed at the two-
pole power switch. At the location of operation, it must be protected by a 10A circuit breaker
(characteristic B). When replacing a fuse, use one of the same type, rating and characteristic.
