COMPONENT LIST
1. Spray gun
2. Trigger switch
3. Spray gun holder
4. On/Off switch
5. Lance with normal nozzle
6. Normal nozzle
7. Outlet
8. Outlet lock knob
9. Wheels*2
10. PVC cable
11. The handle of hose disk
12. Pressure hose
13. Hose disk
14. Handle
15. Holder for PVC cable
16. Lance holder fence
17. Soap pot
18. Inlet water connector
19. Nozzle pin
20. Washer’s screw
21. Water inlet screw
22. Hose controlling button (See Fig. E2)
23. Lock-on/off switch (See Fig. F2)
TECHNICAL DATA
Type WS8675 (86-designation of machinery, representative of high pressure washer)
Rated voltage 220-240V~50/60Hz
Rated power 1800 W
Rated pressure 100 Bar
Max. pressure 150 Bar
Rated flow rate 6 l/min
Maximum flow rate 7 l/min
Protection class
/II
Protection degree IPX5
Weight 8.2kg
NOISE INFORMATION
A weighted sound pressure L
pA
= 73.4 dB(A)
A weighted sound power L
wA
= 86 dB(A)
K
pA
&K
wA
3 dB(A)
Wear ear protection when sound pressure is over 80dB (A) .
VIBRATION INFORMATION
Vibration emission value: Main handle: a
h
= 0.98 m/s² Auxiliary handle: a
h
= 1.02 m/s² Uncertainty K = 0.36 m/s²
WARNING: The vibration emission value during actual use of the power tool can differ from the declared value depending on the
ways in which the tool is used dependant on the following examples and other variations on how the tool is used:
