Weslo Pursuit E21 - Page 8

11. Attach the Backrest (45) to the Seat Upright (64)
with four M6 x 16mm Screws (46).
8
45
46
64
11
12
63
25
26
10
10. Attach the Seat Handles (25) to the Seat Bracket
(63) with two M10 x 97mm Hex Head Bolts (12) and
two M10 Nylon Locknuts (26).
9. Attach the Seat (44) to the Seat Bracket (63) with
four M6 x 16mm Screws (46).
44
63
46
9
12
25
