System Introduction
S E C T I O N 1
1.1 Specifications
Control Panel Specifications
Flexible Zone Configuration:
• 8 Fully Programmable Zones
• 37 Access Codes: 32 User, 1 System Master, 2 Master and 2 Duress
• Expandable to 32 Zones
• Hardwired expansion available using the WSS5108 Eight Zone Expansion Module
• Wireless expansion available using the WSS5132-RS Wireless Zone Expansion Module (up to 32
wireless zones, 900MHz, True Spread Spectrum Technology, Fully Supervised)
• Normally Closed, Single EOL or Double EOL zone supervision
• 2-Wire Smoke Zone
• 27 Zone Types, 8 Programmable Zone Options
Audible Alarm Output:
• Supervised Bell Output (current limited at 3 amps), 12 V
DC
• Steady or Pulsed Output
EEPROM Memory:
• Will not lose programming or system status on complete AC and Battery failure
Programmable Outputs:
• Up to 14 Programmable Voltage Outputs, 26 programmable options
• One High Current (300 mA) PGM output with 2 wire smoke detector capability on main panel
• Maximum Loop Current is 1.5 mA when the 2-wire smoke detector configuration is used
• One Low Current (50 mA) PGM output on main panel
• Eight Additional Low Current (50 mA) PGM outputs available using the WSS5208 module
• Four High Current (1 Amp) PGM outputs Available Using the WSS5204 module
• 1 WSS5204 Output Fully Supervised for Siren Output
Powerful 1 Amp Regulated Power Supply:
• 500 mA Auxiliary Supply, 12 V
DC
• Positive Temperature Coefficient (PTC) components replace fuses
• Supervision for loss of AC Power, Low Battery
• Internal Clock Locked to AC Power Frequency
Power Requirements:
• Transformer = 16.5 VAC, 40VA • Battery = 12 volt 4 Ah minimum rechargeable sealed lead acid
Remote Keypad Specifications:
• 2 Different Keypads Available: • Connect up to 8 Keypads
- WSS5508 8 Zone LED Keypad • Four Wire (Quad) Connection to Keybus
- WSS5500 LCD Alphanumeric Keypad • Built in Piezoelectric Buzzer
Digital Communicator Specifications:
• Supports SIA Format • Event Initiated Personal Paging
• 2 Programmable Phone Numbers • 1 Account number
• Supports LINKS 1000 Cellular Communication • DTMF and Pulse Dialing
• DPDT Line Seizure • Anti-jam Feature
• Split Reporting of Selected Transmissions to Each Telephone Number
System Supervision Features
The WSS5010 continuously monitors a number of possible trouble conditions including:
• AC Power Failure • Trouble by Zone • Fire Trouble
• Telephone Line Trouble • Low Battery Condition • Bell Output Trouble
• Loss of Internal Clock • AUX Power Supply Fault • Tamper by Zone
• Failure to Communicate • Module Fault (Supervisory or Tamper)
False Alarm Prevention Features
• Audible Exit Delay • Audible Exit Fault • Urgency on Entry Delay
• Quick Exit • Swinger Shutdown • Recent Closing Transmission
• Communication Delay
